500x800x1200 Code TK14121

Note: Optional ramp

1500x800x1200Cód. TK14121

Closet Ramp

Code TK11039

The HORIZONTAL fireproof cabinet for one 200-liter drum is constructed with carbon steel plates internally and externally, with a layer of resistant insulation between the plates. It features openings at the top and bottom with a double flame arrestor system that acts as ventilation vents for light and heavy gases. It is the only cabinet designed to withstand 900 degrees Celsius for one hour. It features a reinforced U-shaped sheet metal base at the bottom, a door, and three-point locking with a handle and two keys. It features a false bottom that acts as containment dams, a fireproof roof, and a drip pan. This cabinet will be painted red. This cabinet complies with NFPA, OSHA, NR 20, NB 98, Ordinance 3214/78, and UL 1275 regulations.

(Safe to centralize flammables)

They are built under high quality control and to exacting industrial specifications. They provide secure storage in convenient locations close to work.

Built-in Security

Opening edge on both sides of the cabinet with flame arrester system to prevent explosion when mechanically subjected to mechanical discharges. Built-in, anti-spark lock with three-point locking to prevent unauthorized access.

False bottom with perforated plate type grid and fully removable for collecting liquid in its container (containment dike).

When it comes to grounding fireproof cabinets, Tekin went further, making it very wide in order to provide its customers with the best, closest and most convenient point. In other words, it has grounding points all around, simply by removing a rivet to place a screw and tightening it with its grounding cable.

And thermal insulation according to NBR 17505-4

Built-in Convenience

Continuous closing up, down and side for greater security. It has an easy adjustment system for the shelves. Reinforcement in “U” beam with 3 mm thickness and 100 mm height for less contact with the floor and reinforcement for transportation.

Built-in Quality

Between the double walls, made with No. 18 steel sheets, both internally and externally, there is a layer of high-resistance thermal insulation fully reinforced with internal creases for greater resistance.

Painted in red (Red) for fuel storage - Class III (combustible storage class III).
Painted yellow for storage of flammable liquids in general.
Painted in blue for acid storage.
Painted green for storage of pesticides and insecticides.

Fireproof cabinets can be found in various sizes (according to the customer's needs) and internal divisions (shelves) can be ordered in the desired quantity. Note: Other sizes and colors available upon request. Request a quote for other sizes.

Application:

It is used to store drums and/or canisters containing flammable and combustible liquids.

Used in:

It is used to store flammable, combustible and corrosive liquids in medium and large quantities.

It has a KEEP FIRE AWAY - FLAMMABLE sticker as well as a sticker with instructions for use and standards compatible with the product, on each side of the cabinet.

It has a containment dike, thermal insulation, in accordance with national and international regulatory standards, etc.

Technical Specifications:

Fireproof cabinet model TK 20 for HORIZONTAL drum made of SAE 1010/20 carbon steel.

Operating mode

Place the drum inside the cabinet and keep the doors closed.
